AiPi-Cam-D


1. Overview

AiPi-Cam-D

The AiPi-Cam-D is a camera core board designed by Ai-Thinker Technology for the high-performance Ai-M61-32S module. It is fully pin-compatible with the Ai-WB1-32S-CAM while adding a TF card slot to address the limitations of the Ai-WB1-32S-CAM.
The AiPi-Cam-D defaults to a 2MP pixel camera and exposes all unused pins for convenient development.

2. Development Resources

- User Manual

AiPi-Cam-D Firmware User Manual: Click to View

- Schematic Diagrams

AiPi-Cam-D Schematic: Click to View
AiPi-Cam-Floor Schematic: Click to View

- PCB Resources

Online Open Source Project Address: https://pro.lceda.cn/editor#id=27885809d11b49719e7baa380127acb9
PCB Project File: Click to Download

- Source Code and Firmware

GitHub Source Code: https://github.com/Ai-Thinker-Open/AiPi-BL618-Open-SDK
Coding Source Code: https://axk.coding.net/p/boliu/d/AiPi-BL618-Open-SDK/git
Test Firmware: Click to Download

3. Additional Resources

Camera Data Sheet: Click to Download
AiPi-Cam-D Project Introduction: https://oshwhub.com/ai-thiner_openteam/aipi-cam-d200
