AiPi-Cam-U

1. Overview

---

AiPi-Cam-U

• The AiPi-Cam-U is a USB camera core board specially designed by the Ai-Thinker Co., Ltd. Open Source Team for the Ai-M61-32S module, supporting WiFi6 and BLE5.3. The equipped Ai-M61-32S module features rich peripheral interfaces, including DVP, MJPEG, Display, AudioCodec, USB2.0, SDU, Ethernet (EMAC), SD/MMC (SDH), SPI, UART, I2C, I2S, PWM, GPDAC, GPADC, ACOMP, and GPIO, among others.
• The AiPi-Cam-U integrates a Type-C USB port for connecting USB cameras, with 1MP pixel cameras currently tested and verified.

2. Development Resources

- User Manual

• AiPi-Cam-U Test Firmware User Manual: Download

- Schematic Diagram

• AiPi-Cam-U Camera Core Board Schematic: View

- PCB Resources

• Online PCB Project Address: Download

• PCB Project File: Download

- Source Code and Firmware

• Test Firmware Source Code:View

• Test Firmware: Download

3. Additional Resources

---

• AiPi-Cam-U Project Introduction:View
